Montabert 300
|
 |
|
Reference
Conical: M0300-CP-0850
Chisel: M0300-CE-0850
Pyiramidal: M0300-PP-0850
|
|
Specification:
Overall lenght: 850mm
Diameter: 95mm
Weight: 37Kgs
|
|
|
|
|
Montabert 600
|
|
|
Reference
Conical: M0600-CP-1000
Chisel: M0600-CE-1000
Pyiramidal: M0600-PP-1000
|
|
Specification:
Overall lenght: 1000mm
Diameter: 105mm
Weight: 57Kgs
|
|
|
|
|
Montabert 700
|
|
|
Reference
Conical: M0700-CP-0940
Chisel: M0700-CE-0940
Pyiramidal: M0700-PP-0940
|
|
Specification:
Overall lenght: 940mm
Diameter: 112mm
Weight: 60Kgs
|
|
|
|
|
125 SX (New)
|
|
|
Reference
Conical: M0125N-CP-0750
Chisel: M0125N-CE-0750
Pyiramidal: M0125N-PP-0750
|
|
Specification:
Overall lenght: 750mm
Diameter: 74mm
Weight: 23Kgs
|
|
|
|
|
|
BRH 40
|
|
|
Reference
Conical: M0040-CP-0500
Chisel: M0040-CE-0500
Pyiramidal: M0040-PP-0500
|
|
Specification:
Overall lenght: 500mm
Diameter: 45mm
Weight: 6Kgs
|
|
|
|
|
|
|
BRH 75 / 76 / 90 / 91
|
|
|
Reference
Conical: M0075-CP-0550
Chisel: M0075-CE-0550
Pyiramidal: M0075-PP-0550
|
|
Specification:
Overall lenght: 550mm
Diameter: 60mm
Weight: 13Kgs
|
|
|
|
|
BRH 125
|
|
|
Reference
Conical: M0125-CP-0700
Chisel: M0125-CE-0700
Pyiramidal: M0125-PP-0700
|
|
Specification:
Overall lenght: 700mm
Diameter: 80mm
Weight: 23Kgs
|
|
|
|
|
BRH 125
|
|
|
Reference
Conical: M0125-CP-0800
Chisel: M0125-CE-0800
Pyiramidal: M0125-PP-0800
|
|
Specification:
Overall lenght: 800mm
Diameter: 80mm
Weight: 26Kgs
|
|
|
|
|
|
|
|
BRH 250 / 400 / 450
|
|
|
Reference
Conical: M0250-CP-0850
Chisel: M0250-CE-0850
Pyiramidal: M0250-PP-0850
|
|
Specification:
Overall lenght: 850mm
Diameter: 95mm
Weight: 42Kgs
|
|
|
|
|
|
|
BRH 501 / 570
|
|
|
Reference
Conical: M0501-CP-1000
Chisel: M0501-CE-1000
Pyiramidal: M0501-PP-1000
|
|
Specification:
Overall lenght: 1000mm
Diameter: 114mm
Weight: 72Kgs
|
|
|
|
|
|
|
|
BRH 620
|
|
|
Reference
Conical: M0620-CP-1000
Chisel: M0620-CE-1000
Pyiramidal: M0620-PP-1000
|
|
Specification:
Overall lenght: 1000mm
Diameter: 114mm
Weight: 70Kgs
|
|
|
|
|
BRH 625 / 900
|
|
|
Reference
Conical: M0625-CP-1000
Chisel: M0625-CE-1000
Pyiramidal: M0625-PP-1000
|
|
Specification:
Overall lenght: 1000mm
Diameter: 118mm
Weight: 76Kgs
|
|
|
|
|
|
BRH 750
|
|
|
Reference
Conical: M0750-CP-1100
Chisel: M0750-CE-1100
Pyiramidal: M0750-PP-1100
|
|
Specification:
Overall lenght: 1100mm
Diameter: 120mm
Weight: 80Kgs
|
|
|
|
|
BRH 1100
|
|
|
Reference
Conical: M1100-CP-1220
Chisel: M1100-CE-1220
Pyiramidal: M1100-PP-1220
|
|
Specification:
Overall lenght: 1220mm
Diameter: 140mm
Weight: 120Kgs
|
|
|
|
|
BRP 30
|
|
|
Reference
Conical: M0030-CP-0410
Chisel: M0030-CE-0410
Pyiramidal: M0030-PP-0410
|
|
Specification:
Overall lenght: 410mm
Diameter: 40mm
Weight: 4Kgs
|
|
|
|
|
BRP 45 / 50
|
|
|
Reference
Conical: M0045-CP-0500
Chisel: M0045-CE-0500
Pyiramidal: M0045-PP-0500
|
|
Specification:
Overall lenght: 500mm
Diameter: 50mm
Weight: 7Kgs
|
|
|
|
|
|
BRP 60 / 70
|
|
|
Reference
Conical: M0060-CP-0510
Chisel: M0060-CE-0510
Pyiramidal: M0060-PP-0510
|
|
Specification:
Overall lenght: 510mm
Diameter: 50mm
Weight: 8Kgs
|
|
|
|
|
|
BRP 85 / 95 / 100
|
|
|
Reference
Conical: M0100-CP-0620
Chisel: M0100-CE-0620
Pyiramidal: M0100-PP-0620
|
|
Specification:
Overall lenght: 620mm
Diameter: 62mm
Weight: 13Kgs
|
|
|
|
|
BRP 130 / 140 / 150
|
|
|
Reference
Conical: M0130-CP-0640
Chisel: M0130-CE-0640
Pyiramidal: M0130-PP-0640
|
|
Specification:
Overall lenght: 640mm
Diameter: 74mm
Weight: 18Kgs
|
|
|
|
|
BRP 130 / 140 / 150
|
|
|
Reference
Conical: M0130-CP-0700
Chisel: M0130-CE-0700
Pyiramidal: M0130-PP-0700
|
|
Specification:
Overall lenght: 700mm
Diameter: 74mm
Weight: 21Kgs
|
|
|
|
|
|
BRV 32 / 950 / V1200
|
|
|
Reference
Conical: M0032-CP-1100
Chisel: M0032-CE-1100
Pyiramidal: M0032-PP-1100
|
|
Specification:
Overall lenght: 1100mm
Diameter: 122mm
Weight: 91Kgs
|
|
|
|
|
BRV 42 / 43
|
|
|
Reference
Conical: M0043-CP-1250
Chisel: M0043-CE-1250
Pyiramidal: M0043-PP-1250
|
|
Specification:
Overall lenght: 1250mm
Diameter: 150mm
Weight: 156Kgs
|
|
|
|
|
BRV 52
|
|
|
Reference
Conical: M0052-CP-1350
Chisel: M0052-CE-1350
Pyiramidal: M0052-PP-1350
|
|
Specification:
Overall lenght: 1350mm
Diameter: 162mm
Weight: 199Kgs
|
|
|
|
|
BRV 53
|
|
|
Reference
Conical: M0053-CP-1450
Chisel: M0053-CE-1450
Pyiramidal: M0053-PP-1450
|
|
Specification:
Overall lenght: 1450mm
Diameter: 170mm
Weight: 232Kgs
|
|
Z - 92
|
|
|
Reference
Conical: M092Z-CP-0625
Chisel: M092Z-CE-0625
Pyiramidal: M092Z-PP-0625
|
|
Specification:
Overall lenght: 625mm
Diameter: 76mm
Weight: 17Kgs
|
|
|
|
|
Z - 96
|
|
|
Reference
Conical: M096Z-CP-0660
Chisel: M096Z-CE-0660
Pyiramidal: M096Z-PP-0660
|
|
Specification:
Overall lenght: 660mm
Diameter: 62mm
Weight: 10Kgs
|
|
|
V 1600
|
|
|
Reference
Conical: M1600V-CP-1350
Chisel: M1600V-CE-1350
Pyiramidal: M1600V-PP-1350
|
|
Specification:
Overall lenght: 1350mm
Diameter: 140mm
Weight: 150Kgs
|
|
|
|
|
V 45
|
|
|
Reference
Conical: M045V-CP-1370
Chisel: M045V-CE-1370
Pyiramidal: M045V-PP-1370
|
|
Specification:
Overall lenght: 1370mm
Diameter: 150mm
Weight: 173Kgs
|
|
|
|
|
V 55
|
|
|
Reference
Conical: M055V-CP-1450
Chisel: M055V-CE-1450
Pyiramidal: M055V-PP-1450
|
|
Specification:
Overall lenght: 1450mm
Diameter: 170mm
Weight: 235Kgs
|
|
|
|
